As shown in the figure, you only need to configure this static route on R1, and the two
hosts can communicate with each other normally.

A.

True

B.

False

The switch is connected to the host. What is the common port link type of the switch? ()

A.

Access link

B.

Trunk link

C.

Trunk link

D.

HybriD. link

When accessing across network segments, the source and destination IP will change, and
the source and destination MAC will not change

A.

True

B.

False

In order to distinguish between different users and provide different network services on the AP. Which of the following can be configured through configuration? ()

A.

VT

B.

VAP

C.

VAC

D.

WAP

When using the FTP protocol to upgrade the router software, the transmission mode
should be selected ()

A.

Binary mode

B.

Byte mode

C.

Text mode

D.

Stream byte mode

How to deal with the data frame sent by the Trunki port? ()

A.

When the VLAN ID. is the same as the PVID of the port and is a VLAN ID that the port
allows to pass through, remove the Tag and send the message

B.

When the VLAN ID is different from the PVID of the port, the data frame is discarded

C.

When the VLAN ID. is different from the PVID of the port, replace it with PVID. Forward

D.

When the VLAN ID. is different from the PVID of Jingkou, the TAG is stripped and
forwarded

In the VRP interface, use the command startup saved-configuration backup.cfg. Configure
the startup.cfg file to be used at the next startup ()

A.

True

B.

False

Neither the A1 ternate interface nor the Backup port in RSTP can forward user traffic, nor
can they receive, process, and forward BPDUs ()

A.

True

B.

False

The router needs to modify the destination IP address in the data packet when forwarding
the data packet ()

A.

True

B.

False

The two ends of the PPP link are not in the same network segment and cannot
communicate

A.

True

B.

False
